engineering for gas processing
3S Technology for gas separation was developed in 1997, with worldwide patents and successful field testing. It introduces advanced solutions for processing natural or associated gas in the oil and gas industry.
3S Technology is based on pre-swirled gas flow expansion in a Laval nozzle. At that point, due to the conversion of a portion of the gas flow’s potential energy into actual kinetic energy during its acceleration to supersonic speed, a rapid static pressure drop takes place in the flow, accompanied by its rapid cooling.
3S Technology regulates the flow temperature in the nozzle by means of a calculated selection of nozzle geometry and pressure drop rate (usually characterized by the Mach number « M »). The Mach number is selected in such a way that “targets” gas mixture components (i.e. components to be separated) transfer to a liquid phase. The droplets thus formed actively coagulate, assisted by the turbulent nature of the swirling flow. The flow swirling degree is usually selected so as to provide centrifugal forces in the nozzle working section at the level of about 100 thousand and higher.
Under the influence of centrifugal forces, the liquid droplets are moved into the boundary layer, where the gas-liquid mixture enriched with “target” components is formed. At this stage, the “central” portion of the flow is cleared from the “target” components.
Further on in the selection device, the gas flow is divided into two parts: gas-liquid flow directed into the gas-liquid separator and the flow of prepared (sales) gas directed to the consumer.
The use of diffusers at the outlet of the 3S-separator working part allows for converting some of the kinetic energy into potential energy due to deceleration. This results in substantially greater gas pressure at the outlet of the diffuser than the static pressure of a gas in a Laval nozzle, which is where the condensation of the target components occurs.
Operating principle
3S Technology is based on pre-swirled gas flow expansion in a Laval nozzle. At that point, due to the conversion of a portion of the gas flow's potential energy into actual kinetic energy during its acceleration to supersonic speed, a rapid static pressure drop occurs in the flow, accompanied by its rapid cooling.
3S Technology regulates the nozzle's flow temperature, employing a calculated selection of nozzle geometry and pressure drop rate (usually characterized by the Mach number « M »). The Mach number is selected so that “targets” gas mixture components (i.e. components to be separated) transfer to a liquid phase. The droplets thus formed actively coagulate, assisted by the turbulent nature of the swirling flow. The flow swirling degree is usually selected to provide centrifugal forces in the nozzle working section at the level of about 100 thousand and higher.
Under the influence of centrifugal forces, the liquid droplets are moved into the boundary layer, where the gas-liquid mixture enriched with “target” components is formed. At this stage, the “central” portion of the flow is cleared from the “target” components.
Further on in the selection device, the gas flow is divided into two parts: gas-liquid flow directed into the gas-liquid separator and the flow of prepared (sales) gas directed to the consumer.
Using diffusers at the outlet of the 3S-separator working part allows for converting some of the kinetic energy into potential energy due to deceleration. This results in substantially greater gas pressure at the outlet of the diffuser than the static pressure of a gas in a Laval nozzle, where the condensation of the target components occurs.
KEY BENEFITS
Operational efficiency
High-efficiency gas preparation and separation.
No requirement for labour-intensive or highly skilled ongoing maintenance.
The compact and lightweight design simplifies installation and maintenance.
Energy efficiency
High energy efficiency is achieved by using reservoir energy.
Efficient CO₂ extraction from the sour natural gases.
Environmental safety.
economically viable
Possibility of executing deep recovery of propane-butanes and ethane.
Efficient CO₂ extraction from the sour natural gases.
It can be used on offshore platforms and in underwater gas treatment systems.
how it works
3s technology applications
NGL Recovery
3S Technology enables efficient NGL recovery from natural associated, or flare gas, maximizing production and revenue while reducing environmental impact. It integrates seamlessly with existing plants and pipelines, allowing for NGL separation for sale or internal use in power and compressor systems.
gas conditioning
3S Technology revolutionizes natural gas processing with advanced conditioning and enrichment solutions. It ensures compliance with pipeline standards by efficiently separating NGLs and water, while its enrichment capabilities boost target component concentrations, enhancing GPP efficiency and capacity.
3s technology applications
NGL Recovery
3S Technology enables efficient NGL recovery from natural associated, or flare gas, maximizing production and revenue while reducing environmental impact. It integrates seamlessly with existing plants and pipelines, allowing for NGL separation for sale or internal use in power and compressor systems.
gas conditioning
3S Technology revolutionizes natural gas processing with advanced conditioning and enrichment solutions. It ensures compliance with pipeline standards by efficiently separating NGLs and water, while its enrichment capabilities boost target component concentrations, enhancing GPP efficiency and capacity.
CO2 Separation
3S Technology allows the separation of CO2 from natural gas, substantially improving the cost efficiency of processing natural gas with high CO2 levels & making such projects economically viable. The separated CO2 can be further injected back or used to increase extraction rates of oil deposits.
CO₂ Separation
3S Technology allows the separation of CO₂ from natural gas, substantially improving the cost efficiency of processing natural gas with high CO₂ levels & making such projects economically viable. The separated CO₂ can be further injected back or used to increase extraction rates of oil deposits.
3s technology applications
NGL Recovery
3S Technology enables efficient NGL recovery from natural associated or flare gas, maximizing production and revenue while reducing environmental impact. It integrates seamlessly with existing plants and pipelines, allowing for NGL separation for sale or internal use in power and compressor systems.
gas conditioning
3S Technology revolutionizes natural gas processing with advanced conditioning and enrichment solutions. It ensures compliance with pipeline standards by efficiently separating NGLs and water, while its enrichment capabilities boost target component concentrations, enhancing GPP efficiency and capacity.
Our services
Scheme Development
Development of technological diagrams for 3S separator installation adjusted for each client.
Flow Calculation and Design
Design works and development of the manufacturing documentation for 3S separators.
Manufacturing and Delivery
Ordering and monitoring the manufacture and delivery of the project equipment.
Organization of Installation Works
Development of a project for 3S separator installation and embedding.
Implementation Supervision
Supervision of the 3S separator installation and commissioning works.
Training of Personnel
Training and education of your personnel.
